AD Shelter Steri  [UHF RFID tag and inlay]

UHF RFID Inlay: AD Shelter Steri

Withstands the harshest sterilization — Autoclave, EtO, and gamma-resistant RFID

Industry segments: Healthcare

AD Shelter Steri is a sterilization-proof RFID tag engineered to maintain full performance and resist damage from major sterilization methods: gamma radiation, autoclave, and EtO (ethylene oxide). Designed for the following substrates: PP, Glass Vial, PP Panel, and Glass Panel.

The product has been evaluated for compatibility with common sterilization methods used in medical and healthcare applications.

All sterilization tests were conducted under validated laboratory conditions to ensure material integrity and performance consistency after sterilization.

Avery Dennison inlays and tags are compliant with ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management, which ensure a reliable and state-of-the-art product that meets a variety of application needs.

Please find a comprehensive overview of all features in the data sheet.

UHF RFID Inlay: AD Shelter KX2005X-S Steri

AD Shelter KX2005X-S Steri

  • Chip: Kiloway KX2005X-S
  • Frequency Band:
    UHF 860 - 960 MHz
  • Antenna Dimensions:
    12.5 x 30 mm / 0.49 x 1.18 in (NEL)
    30 x 12.5 mm / 1.18 x 0.49 in (WEL)
  • Die Cut Dimensions:
    18 x 51.1 mm / 0.7x 2.0 in
    33 x 51.1 mm / 1.3 x 2.0 in
  • EPC memory: 96 - 128 bits
  • TID memory: 96-bit / 48-bit unique serial number
  • Product Code:
    Label / sticker  IL-610047 (NEL)
    Label / sticker  IL-610052 (WEL)
