AD Nanoblock [HF RFID tag and inlay]

Tiny, powerful square inlay for use where space is at a premium

Industry segments: Apparel and Fashion, Beauty and Personal Care, Food, Healthcare, Industrial Applications

AD Nanoblock is one of smallest HF/NFC inlays in the market (4.5 x 4.5 mm), delivering excellent performance for healthcare applications, product authentication, and item-level tagging in space-constrained environments. It is excellent for consumer engagement and experience, and brand protection use-cases. Complying to NFC Type 5, which offers support for the ISO/IEC 15693 specification, the tag also offers the flexibility of NFC, which allows it to be read by any suitable modern smartphone.

The AD Nanoblock is extremely compact, delivering enhanced performance with its copper-based design.

Avery Dennison inlays and tags are compliant with ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management, which ensure a reliable and state-of-the-art product that meets a variety of application needs.

Please find a comprehensive overview of all features in the data sheet.

AD Nanoblock SLIX HC

Chip: NXP ICODE SLIX HC
Frequency Band:
HF 13,56 MHz
Antenna Dimensions:
4.5 x 4.5 mm / 0.177 x 0.177 in
Die-Cut Dimensions:
5.5 x 5.5 mm / 0.217 x 0.217 in
EPC Memory: -
Product Code:
Dry inlay IL-612844
Wet+ inlay IL-612842

Data sheet

AD Nanoblock ICODE 3

Chip: NXP ICODE 3
Frequency Band:
HF 13,56 MHz
Antenna Dimensions:
4.5 x 4.5 mm / 0.177 x 0.177 in
Die-Cut Dimensions:
5.5 x 5.5 mm / 0.217 x 0.217 in
EPC Memory: -
Product Code:
Dry inlay IL-613409
Wet+ inlay IL-613407

Data sheet
