AD Miniweb M830 ETSI Pure™ [UHF RFID tag and inlay]

UHF RFID Inlay: AD Miniweb M830 ETSI Pure™

Compact, plastic free RFID inlay for sustainable item-level tagging

Industry segments: Apparel & Fashion,  LogisticsGeneral Retail

AD Miniweb M830 ETSI Pure™ inlays are designed for a broad range of applications, including inventory and logistics, electronics, sporting goods, home essentials, and general merchandise. The popular Apparel design is an excellent choice for retailers looking to tag diverse merchandise, as it provides consistent high read rates with a small label footprint. In addition, these inlays are particularly effective on materials such as glass and plastic.

These inlays and tags are compliant with ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management, which ensure a reliable and state-of-the-art product that meets a variety of application needs.  Like all RFID products from Avery Dennison, AD Miniweb M830 ETSI Pure inlays are manufactured according to the industry’s highest quality standards, as confirmed by the RFID Lab at Auburn University: The inspection body awarded Avery Dennison its first comprehensive and significant ARC accreditation for quality.

_________________________________
1Additional components, product application, or other attributes may change the final recyclability of the package.

AD Pure™ Product Line

This inlay is part of the AD Pure™ range, Avery Dennison's portfolio of the new generation of RFID inlays and labels with lowest possible carbon footprint currently in the market. The pure aluminum PET-free antennas are manufactured with innovative technologies allowing 70-90% lower carbon footprint compared to traditional etching. Like all RFID products from Avery Dennison, The Pure™ inlays are manufactured according to industry’s highest quality standards as confirmed by the RFID Lab at Auburn University and are available in wet and label formats.

Please find a comprehensive overview of all features in the data sheet.

UHF RFID Inlay: Miniweb M830 ETSI Pure

AD Miniweb M830 ETSI Pure™

  • Chip: Impinj M830
  • Frequency Band:
    UHF (860-960 Mhz)
  • Antenna Dimensions:
    42 x 16 mm / 1.70 x 0.60 in
  • Die Cut Dimensions:
    44 x 18 mm / 1.80 x 0.70 in
  • EPC Memory: 96 bits
  • TID Memory: 96-bit / 48-bit unique serial number
  • ARC Specification
  • Product Code:
    Dry inlay IL-611677
    Wet inlay IL-611667
    Label / sticker IL-611665
    Label / sticker IL-612795
