AD Microtrack SLIX HC [HF RFID tag and inlay]

HF RFID Inlay: Microtrack
HF RFID Inlay: Microtrack

Small tag - top performance for healthcare

Industry segments: Healthcare, Industrial Applications

Avery Dennison Smartrac's Microtrack inlays and tags are designed for healthcare applications and pharmaceutical product authentication. Microtrack is a high end product for demanding item level applications.

Microtrack inlays and tags are equipped with NXP ICode SLIX provides 896 bits of user memory, while Microtrack with Infineon my-d vicinity 2k offers 1792 bits, or with Infineon my-d vicinity 10k provides 7936 bits extended user memory. The tags deliver excellent performance for small item level packages, wristbands and other pharmaceutical applications. Its small size fits an easy labelling or sticker usage on small goods.

The inlays and tags are compliant with ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management. This ensures a reliable and state-of-the-art product that meets a variety of application needs, where high performance is a critical parameter.

Technical Features

Chip
NXP ICode SLIX HC
Infineon my-d vicinity 2k
Frequency Band
HF 13.56 MHz
Antenna Dimensions 20 x 10 mm / 0.79 x 0.39 in
Die Cut Dimensions 22 x 12 mm / 0.87 x 0.47 in
Product Code Dry+ inlay 3002551 /  IL-602744  (SLIX HC)
Wet+ inlay 3003186  / IL-602788 (SLIX HC)
Wet+ inlay 3006716 / IL-603191 (my-d vicinity 2k)

Please find a comprehensive overview of all features in the data sheet.
