AD Glow [UHF RFID tag and inlay]

UHF RFID Inlay: AD Glow U9

Auburn University ARC certified for General Retail spec C2

Industry segments:  General Retail

AD Glow inlays are designed to meet Auburn University's C2 general retail specification. These inlays offer excellent global performance and are ideal for a wide range of retail applications, including decor, hardware, candles, and other home goods, as well as cosmetics. AD Glow inlays offer a compact die-cut footprint making them perfect for use on smaller retail items.

These inlays and tags are compliant with ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management, which ensure a reliable and state-of-the-art product that meets a variety of application needs.  Like all RFID products from Avery Dennison, AD Glow inlays are manufactured according to the industry’s highest quality standards, as confirmed by the RFID Lab at Auburn University: The inspection body awarded Avery Dennison its first comprehensive and significant ARC accreditation for quality.

Please find a comprehensive overview of all features in the data sheet.

UHF RFID Inlay:  AD Glow U9

AD Glow U9

  • Chip: NXP UCODE 9
  • Frequency band:
    UHF (860-960 Mhz)
  • Antenna dimensions:
    42.50 x 17 mm / 1.67 x 0.67 in
  • Die cut dimensions:
    44.45 x 19.05 mm / 1.75 x 0.75 in
  • EPC memory: 96 bit
  • TID memory: 96-bit / 48-bit unique serial number
  • ARC specification
  • Product code:
    Dry inlay IL-613317
    Dry inlay IL-612879
    Wet inlay IL-613318
    Wet inlay IL-612885
    Label/sticker IL-613311
    Label/sticker IL-612891
    Label/sticker IL-612892
