AD Dazzle M830 Pure™ [UHF RFID tag and inlay]

UHF RFID Inlay: AD-333 U9 Pure

Optimum read ranges for small item level tagging

Industry segments: Apparel and FashionBeauty and Personal Care, General Retail

AD Dazzle M830 Pure inlays are designed for tagging a wide range of items, particularly beauty & personal care products, fashion and jewelry accessories and other general merchandise. Built for the UHF frequency band, the inlays feature a 30 x 15 mm antenna with a global design. The slender form factor and rectangular shape further contributes to the versatile use in retail oriented applications to increase inventory accuracy, improve supply chain agility, and enhance visibility across all channels.

These inlays and tags are compliant with ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management, which ensure a reliable and state-of-the-art product that meets a variety of application needs.  Like all RFID products from Avery Dennison, AD Dazzle M830 Pure  inlays are manufactured according to the industry’s highest quality standards, as confirmed by the RFID Lab at Auburn University: The inspection body awarded Avery Dennison its first comprehensive and significant ARC accreditation for quality.

AD Pure™ Product Line

This inlay is part of the AD Pure™ range, Avery Dennison's portfolio of the new generation of RFID inlays and labels with lowest possible carbon footprint currently in the market. The pure aluminum PET-free antennas are manufactured with innovative technologies allowing 70-90% lower carbon footprint compared to traditional etching. Like all RFID products from Avery Dennison, The Pure™ inlays are manufactured according to industry’s highest quality standards as confirmed by the RFID Lab at Auburn University and are available in wet and label formats.

Please find a comprehensive overview of all features in the data sheet.

UHF RFID Inlay:  AD Dazzle M830 Pure

AD Dazzle M830 Pure™

  • Chip: Impinj M830
  • Frequency band:
    UHF (860-960 Mhz)
  • Antenna dimensions:
    30 x 15 mm / 1.20 x 0.60 in
  • Die cut dimensions:
    33 x 18 mm / 1.30 x 0.70 in
  • EPC memory: 96 bits
  • TID memory: 96-bit / 48-bit unique serial number
  • ARC specification
  • Product code:
    Dry inlay: IL-613356
    Wet inlay: IL-613355
    Label/sticker: IL-613354
