Industry segments: Apparel & Fashion, Logistics
Avery Dennison Smartrac’s Eagle™ is one of the smallest global RFID inlays for retail applications, having a compact size 44 x 28 mm which can be easily converted into end-application usage, available in dry and paper-tag delivery formats. Eagle equipped with NXP UCode 8 offers the same memory size and typical IC features as NXP UCode 7. Furthermore, it offers a Self Adjust feature to maximize product performance in challenging environments and has an improved read and write sensitivity and faster encoding speed compared to NXP UCode 7. The chip has an integrated Brand Identifier function to prove product authenticity and a memory safeguard system to protect business data.
Eagle with the NXP UCode 8 IC, used in retail applications, is the smallest inlay with global performance currently available on the market that has passed ARC categories A, B, C, D, F, G, I, K, M, Q, W2 and W5.
Our Eagle™M730 is one of the smallest UHF RFID inlays with superior global RF performance for apparel and retail applications. Having a compact size 44 x 28 mm which can be easily converted into end application usage, Eagle is available in dry, wet and label delivery formats.
Eagle™ products are available with the Impinj M730 and M750 ICs, offering high performance across different materials and challenging environments due to enhanced adaptive RF tuning features. The Impinj M730 IC has 128-bit EPC memory, and the
Impinj M750 IC has both 96-bit EPC memory and 32-bit user memory. Both Impinj ICs are compatible with the global GS1 UHF Gen2v2 standard which ISO/IEC standardized as 18000-63.
Eagle with both Impinj M730 and M750, is included on the approved retail application inlay list by the RFID Research Center (ARC) of the University of Auburn, and complies with categories F, G, I, K, M, Q, N, L, W1, W2, W3, W4, W5, and W6.
The inlays and tags are compliant with ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management, which ensure a reliable and state-of-the-art product that meets a variety of application needs, especially in the retail environment.
Please find a comprehensive overview of all features in the data sheet.
AD Eagle U8
AD Eagle U9
AD Eagle M730
Avery Dennison Smartrac offers the broadest product range for any RFID challenge and ensures consistent quality and performance. Check our RFID product recommendations for the Apparel industry segment.
RFID tags offer retailers a wealth of benefits that are becoming increasingly important in this highly competitive sector. Retail applications demand excellent performance, reliability and – in many cases – a compact form factor from the applied tags. Avery Dennison Smartrac's all-new RAIN RFID Eagle tags satisfy all these demands.
