UHF RFID Inlay: AD-456u8

UHF RFID Inlay: AD-456

Robust and versatile labels for hard to read surfaces

Industry segments: Beauty & Personal Care, Food


Available in both FCC and ETSI versions, AD-456u8 inlays from Avery Dennison are an excellent option for tagging items that cannot be RFID-enabled with traditional inlay designs.

Equipped with a UCODE 8 chip from NXP, the Gen2 UHF RFID RAIN labels are hence perfectly suited for applications related to manufacturing, computers and electronics, and miscellaneous consumer goods, including beverages such as bottled water, juices, and soft drinks in aluminum cans. AD-456u8 inlays are robust, high performing and incredibly versatile solutions for tagging hard to read surfaces.

The product’s UCODE 8 chip features 128 bits of EPC memory and 96 bit unique factory-locked TID number. A 48 bit unique serial number is factory-encoded into the TID. The sole delivery format is Pressure Sensitive Label.

Like all RFID products from Avery Dennison Intelligent Labels, AD-456u8 inlays are manufactured according to the industry's highest quality standards, as confirmed by the RFID Lab at Auburn University: The inspection body awarded Avery Dennison its first comprehensive and significant ARC accreditation for quality.

Please find a comprehensive overview of all features in the data sheet.

UHF RFID Inlay:  AD-456u8 ETSI

AD-456u8 ETSI

  • Chip: NXP UCODE 8
  • Frequency Band:
    UHF (860-960 Mhz)
  • Antenna Dimensions:
    64 x 6 mm / 2.52 x 0.236 in
  • Die Cut Dimensions:
    64 x 6 mm / 2.52 x 0.24 in
  • EPC Memory: 128 bits
  • TID Memory: 96-Bit Tag IDentifier & 48-Bit
UHF RFID Inlay: AD-456u8 ETSI Large Die Cut

AD-456u8 ETSI Large Die Cut

  • Chip: NXP UCODE 8
  • Frequency Band:
    UHF (860-960 Mhz)
  • Antenna Dimensions:
    64 x 18 mm / 2.52 x 0.709 in
  • Die Cut Dimensions:
    64 x 18 mm / 2.52 x 0.71 in
  • EPC Memory: 128 bits
  • TID Memory: 96-Bit Tag IDentifier & 48-Bit
UHF RFID Inlay: AD-456u8 FCC

AD-456u8 FCC

  • Chip: NXP UCODE 8
  • Frequency Band:
    UHF (860-960 Mhz)
  • Antenna Dimensions:
    64 x 6 mm / 2.52 x 0.236 in
  • Die Cut Dimensions:
    64 x 6 mm / 2.52 x 0.24 in
  • EPC Memory: 128 bits
  • TID Memory: 96-Bit Tag IDentifier & 48-Bit
UHF RFID Inlay:  AD-456u8 FCC Large Die Cut

AD-456u8 FCC Large Die Cut

  • Chip: NXP UCODE 8
  • Operating frequency:
    UHF (860-960 Mhz)
  • Antenna dimensions:
    64 x 18 mm / 2.52 x 0.709 in
  • Die cut dimensions:
    64 x 18 mm / 2.52 x 0.71 in
  • EPC memory: 128 bits
  • TID memory: 96-Bit Tag IDentifier & 48-Bit
UHF RFID Inlay:  AD-456u8 ETSI Tamper-Evident

AD-456u8 ETSI Tamper-Evident

  • Chip: NXP UCODE 8
  • Operating frequency:
    UHF (860-960 Mhz)
  • Antenna dimensions:
    64 x 6 mm / 2.52 x 0.24 in
  • Die cut dimensions:
    64 x 18 mm / 2.52 x 0.24 in
  • EPC memory: 128 bits
  • TID memory: 96-Bit Tag IDentifier & 48-Bit
